130BF682.10
A
20 (0.8)
0 (0.0)
35(1.4)
0 (0.0)
15 (0.6)
35 (1.4)
50 (2.0)
75 (3.0)
90 (3.5)
125 (4.9)
140 (5.5)
8X 14 (0.5)
2X 125 (4.9)
0 (0.0)
0 (0.0)
234 (9.2)
314 (12.4)
0 (0.0)
219 (8.6)
A
Figure 8.95 E4h Load Share/Regen Terminal Dimensions
Exterior and Terminal Dimen...
VLT
®
AQUA Drive FC 202
148 Danfoss A/S © 01/2018 All rights reserved. MG22B222
