Model
N110K N132 N160 N200 N250 N315
Cycle time (s) 600 600 600 600 600 600
Braking duty cycle at
100% torque
Continuous Continuous Continuous Continuous Continuous Continuous
Braking duty cycle at
150/160% torque
10% 10% 10% 10% 10% 10%
Table 10.19 D1h–D8h Braking Capability, 380–480 V
Model
N355 N400 N450 N500 N560
Nominal braking
[45 °C (113 °F)]
Cycle time (s) 600 600 600 600 600
Current (%) 100 70 62 56 80
Braking time (s) 240 240 240 240 240
Overload braking
[45 °C (113 °F)]
Cycle time (s) 300 300 300 300 300
Current (%) 136 92 81 72 107
Braking time (s) 30 30 30 30 30
Nominal braking
[25 °C (77 °F)]
Cycle time (s) 600 600 600 600 600
Current (%) 100 92 81 89 80
Braking time (s) 240 240 240 240 240
Overload braking
[25 °C (77 °F)]
Cycle time (s) 300 300 300 300 300
Current (%) 136 113 100 72 107
Braking time (s) 30 10 10 30 30
Table 10.20 E1h–E4h Braking Capability, 380–480 V
Model
N75K N90K N110K N132 N160 N200 N250 N315 N400
Cycle time (s) 600 600 600 600 600 600 600 600 600
Braking duty
cycle at 100%
torque
40 40 40 40 40 40 40 40 40
Braking duty
cycle at
150/160% torque
10 10 10 10 10 10 10 10 10
Table 10.21 D1h–D8h Braking Capability, 525–690 V
Model
N450 N500 N560 N630 N710 N800
Nominal braking
[45 °C (113 °F)]
Cycle time (s) 600 600 600 600 600 600
Current (%) 89 79 63 63 71 63
Braking time (s) 240 240 240 240 240 240
Overload braking
[45 °C (113 °F)]
Cycle time (s) 300 300 300 300 300 300
Current (%) 113 100 80 80 94 84
Braking time (s) 30 30 30 30 30 30
Nominal braking
[25 °C (77 °F)]
Cycle time (s) 600 600 600 600 600 60
Current (%) 89 79 63 63 71 63
Braking time (s) 240 240 240 240 240 240
Overload braking
[25 °C (77 °F)]
Cycle time (s) 300 300 300 300 300 300
Current (%) 113 100 80 80 94 84
Braking time (s) 30 30 30 30 30 30
Table 10.22 E1h–E4h Braking Capability, 525–690 V
Electrical Installation Con...
VLT
®
AQUA Drive FC 202
168 Danfoss A/S © 01/2018 All rights reserved. MG22B222
