Danfoss VLT AQUA Drive FC 202 Design Manual

10.14.1 EMC Test Results
The following test results have been obtained using a drive (with options if relevant), a shielded control cable, a control box
with potentiometer, a motor, and motor shielded cable.
RFI lter type Conducted emission Radiated emission
Standards/
requirements
EN 55011 Class B
Housing, trades
and light
industries
Class A
group 1
Industrial
environment
Class A group
2
Industrial
environment
Class B
Housing, trades
and light
industries
Class A group 1
Industrial
environment
Class A group 2
Industrial
environment
EN/IEC
61800-3
Category C1
First
environment
Home and
oce
Category C2
First
environment
Home and
oce
Category C3
Second
environment
Industrial
Category C1
First
environment
Home and oce
Category C2
First
environment
Home and oce
Category C3
First environment
Home and oce
H2
FC 202 110–560 kW
380–480 V
No No 150 m
(492 ft)
No No Yes
90–800 kW
525–690 V
No No 150 m
(492 ft)
No No Yes
H4
FC 202 110–560 kW
380–480 V
No 150 m
(492 ft)
150 m
(492 ft)
No Yes Yes
90–800 kW
525–690 V
– – – – – –
Table 10.37 EMC Test Results (Emission and Immunity)
10.14.2 Emission Requirements
According to the EMC product standard for adjustable speed drives EN/IEC 61800-3:2004, the EMC requirements depend on
the environment in which the drive is installed. These environments along with the mains voltage supply requirements are
dened in Table 10.38.
The drives comply with EMC requirements described in IEC/EN 61800-3 (2004)+AM1 (2011), category C3, for equipment
having greater than 100 A per-phase current draw, installed in the second environment. Compliance testing is performed
with a 150 m (492 ft) shielded motor cable.
Category
(EN 61800-3)
Denition Conducted emission
(EN 55011)
C1 First environment (home and oce) with a supply voltage less than 1000 V. Class B
C2 First environment (home and oce) with a supply voltage less than 1000 V, which
is not plug-in or movable and where a professional is intended to be used to
install or commission the system.
Class A Group 1
C3 Second environment (industrial) with a supply voltage lower than 1000 V. Class A Group 2
C4 Second environment with the following:
•
Supply voltage equal to or above 1000 V.
•
Rated current equal to or above 400 A.
•
Intended for use in complex systems.
No limit line.
An EMC plan must be made.
Table 10.38 Emission Requirements
Electrical Installation Con...
VLT
®
AQUA Drive FC 202
180 Danfoss A/S © 01/2018 All rights reserved. MG22B222
