Danfoss VLT AQUA Drive FC 202 Design Manual

VLT
®
AQUA Drive FC 202
N355 N400 N450
High/normal load HO NO HO NO HO NO
(High overload=150% current during 60 s,
normal overload=110% current during 60 s)
Typical shaft output at 400 V [kW] 315 355 355 400 400 450
Typical shaft output at 460 V [hp] 450 500 500 600 550 600
Typical shaft output at 480 V [kW] 355 400 400 500 500 530
Enclosure size E1h/E3h E1h/E3h E1h/E3h
Output current (3-phase)
Continuous (at 400 V) [A] 600 658 658 745 695 800
Intermittent (60 s overload) (at 400 V) [A] 900 724 987 820 1043 880
Continuous (at 460/480 V) [A] 540 590 590 678 678 730
Intermittent (60 s overload) (at 460/480 V) [A] 810 649 885 746 1017 803
Continuous kVA (at 400 V) [kVA] 416 456 456 516 482 554
Continuous kVA (at 460 V) [kVA] 430 470 470 540 540 582
Maximum input current
Continuous (at 400 V) [A] 578 634 634 718 670 771
Continuous (at 460/480 V) [A] 520 569 569 653 653 704
Maximum number and size of cables per phase (E1h)
- Mains and motor without brake [mm
2
(AWG)]
5x240 (5x500 mcm) 5x240 (5x500 mcm) 5x240 (5x500 mcm)
- Mains and motor with brake [mm
2
(AWG)]
4x240 (4x500 mcm) 4x240 (4x500 mcm) 4x240 (4x500 mcm)
- Brake or regeneration [mm
2
(AWG)]
2x185 (2x350 mcm) 2x185 (2x350 mcm) 2x185 (2x350 mcm)
Maximum number and size of cables per phase (E3h)
- Mains and motor without brake [mm
2
(AWG)]
6x240 (6x500 mcm) 6x240 (6x500 mcm) 6x240 (6x500 mcm)
- Mains and motor with brake [mm
2
(AWG)]
2x185 (2x350 mcm) 2x185 (2x350 mcm) 2x185 (2x350 mcm)
- Load share or regeneration [mm
2
(AWG)]
4x185 (4x350 mcm) 4x185 (4x350 mcm) 4x185 (4x350 mcm)
Maximum external mains fuses [A]
2)
800 800 800
Estimated power loss at 400 V [W]
2), 3)
6178 6928 6851 8036 7297 8783
Estimated power loss at 460 V [W]
2), 3)
5322 5910 5846 6933 7240 7969
Eciency
3)
0.98 0.98 0.98
Output frequency 0–590 Hz 0–590 Hz 0–590 Hz
Heat sink overtemperature trip [°C (°F)]
110 (230) 110 (230) 110 (230)
Control card overtemperature trip [°C (°F)]
80 (176) 80 (176) 80 (176)
Power card overtemperature trip [°C (°F)]
85 (185) 85 (185) 85 (185)
Fan power card overtemperature trip [°C (°F)]
85 (185) 85 (185) 85 (185)
Active in-rush card overtemperature trip [°C (°F)]
85 (185) 85 (185) 85 (185)
Table 7.3 Electrical Data for Enclosures E1h/E3h, Mains Supply 3x380–480 V AC
1) For fuse ratings, see chapter 10.5 Fuses and Circuit Breakers.
2) Typical power loss is at normal conditions and expected to be within
± 15% (tolerance relates to variety in voltage and cable conditions). These
values are based on a typical motor eciency (IE/IE3 border line). Lower eciency motors add to the power loss in the drive. Applies for
dimensioning of drive cooling. If the switching frequency is higher than the default setting, the power losses can increase. LCP and typical control
card power consumptions are included. For power loss data according to EN 50598-2, refer to drives.danfoss.com/knowledge-center/energy-
eciency-directive/#/. Options and customer load can add up to 30 W to the losses, though usually a fully loaded control card and options for
slots A and B each add only 4 W.
3) Measured using 5 m (16.4 ft) shielded motor cables at rated load and rated frequency. Eciency measured at nominal current. For energy
eciency class, see chapter 7.5 Ambient Conditions. For part load losses, see drives.danfoss.com/knowledge-center/energy-eciency-directive/#/.
Specications Design Guide
MG22B222 Danfoss A/S © 01/2018 All rights reserved. 43
7 7
