Danfoss VLT AQUA Drive FC 202

130BF669.10
404 (15.9)
298 (11.7)
105
Figure 8.4 Door Clearance for D1h
130BF607.10
205 (8.1)
138 (5.4)
274 (10.8)
27 (1.0)
137 (5.4)
1
2
1 Mains side 2 Motor side
Figure 8.5 Gland Plate Dimensions for D1h
