8.1.2 D1h Terminal Dimensions
88 (3.5)
0.0
200 (7.9)
130BF342.10
0.0
94 (3.7)
293 (11.5) 263 (10.4)
33 (1.3) 62 (2.4)
101 (4.0) 140 (5.5) 163 (6.4) 185 (7.3) 224 (8.8)
2
1
3
1 Mains terminals 3 Motor terminals
2 Ground terminals – –
Figure 8.6 D1h Terminal Dimensions (Front View)
