Danfoss VLT AQUA Drive FC 202

8.2.2 D2h Terminal Dimensions
130BF345.10
143 (5.6)
168 (6.6)
331 (13.0)
211 (8.3)
168 (6.6)
143 (5.6)
42 (1.6) 68 (2.7)
126 (5.0) 184 (7.2) 246 (9.7)
300 (11.8) 354 (13.9) 378 (14.9)
0.0
0.0
2
1
3
1 Mains terminals 3 Motor terminals
2 Ground terminals – –
Figure 8.13 D2h Terminal Dimensions (Front View)
Exterior and Terminal Dimen...
VLT
®
AQUA Drive FC 202
68 Danfoss A/S © 01/2018 All rights reserved. MG22B222
