Danfoss VLT AQUA Drive FC 202 Design Manual

130BF351.10
1
2
0.0
33 (1.3) 0.0 62 (2.4) 101 (4.0) 140 (5.5) 163 (6.4) 185 (7.3) 191 (7.5) 224 (8.8) 256 (10.1) 263 (10.4) 293 (11.5)
511 (20.1)
517 (20.4)
623 (24.5)
727 (28.6)
3
4
1 Mains terminals 3 Motor terminals
2 Brake terminals 4 Ground terminals
Figure 8.33 D5h Terminal Dimensions with Brake Option (Front View)
Exterior and Terminal Dimen... Design Guide
MG22B222 Danfoss A/S © 01/2018 All rights reserved. 87
8 8
