Danfoss VLT AQUA Drive FC 202 Design Manual

8.6.2 D6h Terminal Dimensions
130BF353.10
0.0
96 (3.8)
195 (7.7)
227 (8.9)
123 (4.8)
153 (6.0)
458 (18.0)
0.0
46 (1.8) 50 (2.0) 99 (3.9)
147 (5.8) 182 (7.2) 193 (7.6) 221 (8.7) 249 (9.8)
260 (10.2)
146 (5.8)
3
2
1
4
5
1 Mains terminals 4 Brake terminals
2 Ground terminals 5 Motor terminals
3 TB6 terminal block for contactor – –
Figure 8.41 D6h Terminal Dimensions with Contactor Option (Front View)
Exterior and Terminal Dimen...
VLT
®
AQUA Drive FC 202
94 Danfoss A/S © 01/2018 All rights reserved. MG22B222
