Terminal Overview
Terminal number Descriptive Name Encoder 2
(Feedback)
1 +24 V Supply
2 +8 V Supply
3 +5 V Supply
4 GND
5 A
6 A not
7 B
8 B not
9 Z/Clock
10 Z not/Clock not
11 DATA
12 DATA not
Table 11.5 Terminal Block X55
Terminal number Descriptive Name Encoder 1 (Master)
1 +24 V Supply
2 N/A
3 +5V Supply
4 GND
5 A
6 A not
7 B
8 B not
9 Z/Clock
10 Z not/Clock not
11 DATA
12 DATA not
Table 11.6 Terminal Block X56
Terminal number Descriptive Name Digital inputs
1 Digital Input
2 Digital Input
3 Digital Input
4 Digital Input
5 Digital Input
6 Digital Input
7 Digital Input
8 Digital Input
9 Digital Input
10 Digital Input
Table 11.7 Terminal Block X57
Terminal number Descriptive Name Supply
1 +24 V Supply
2 GND
Table 11.8 Terminal Block X58
Terminal number Descriptive Name Digital outputs
1 Digital Output/Input
2 Digital Output/Input
3 Digital Output
4 Digital Output
5 Digital Output
6 Digital Output
7 Digital Output
8 Digital Output
Table 11.9 Terminal Block X59
Terminal number MCO Debug (RS-485)
1
CS
Control Select
62 RxD/TxD - P
63 RxD/TxD - N
66 0 V
67 +5 V
Table 11.10 Terminal Block X60
Terminal number MCO CAN Bus
1 N/A
2 CAN - L
3 DRAIN
4 CAN - H
5 N/A
Table 11.11 Terminal Block X62
11.3.1
VLT
®
Motion Control Option MCO
305
The MCO 305 is an integrated free programmable motion
controller for FC 301 and FC 302, for more information, see
chapter 11.3.1 Motion Control Options.
11.3.2
VLT
®
Synchronising Controller MCO
350
NOTICE
Terminal block X59 has fixed functionality for MCO 350.
NOTICE
Terminal block X62 is not supported for MCO 350.
NOTICE
Terminal block X60 is not used for MCO 350.
For more information, see chapter 11.3.1 Motion Control
Options.
Options and Accessories
VLT
®
AutomationDrive FC 301/FC 302 Design Guide, 0.25-75 kW
MG33BF02 - Rev. 2013-12-20 169
