Danfoss VLT AutomationDrive FC 301 Design Guide

12.7.7 The PKE Field
The PKE field contains 2 sub-fields: Parameter command
and response AK, and Parameter number PNU:
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
130BA268.10
PKE IND
PWE
high
PWE
low
AK PNU
Parameter
commands and replies
Parameter number
Illustration 12.10 PKE Field
Bits no. 12-15 transfer parameter commands from master
to follower and return processed follower responses to the
master.
Bit no. Parameter command
15 14 13 12
0 0 0 0 No command
0 0 0 1 Read parameter value
0 0 1 0 Write parameter value in RAM (word)
0 0 1 1 Write parameter value in RAM (double
word)
1 1 0 1 Write parameter value in RAM and
EEprom (double word)
1 1 1 0 Write parameter value in RAM and
EEprom (word)
1 1 1 1 Read/write text
Table 12.4 Parameter Commands Master ⇒ Follower
Bit no. Response
15 14 13 12
0 0 0 0 No response
0 0 0 1 Parameter value transferred (word)
0 0 1 0 Parameter value transferred (double
word)
0 1 1 1 Command cannot be performed
1 1 1 1 text transferred
Table 12.5 Response Follower⇒ Master
If the command cannot be performed, the follower sends
this response:
0111 Command cannot be performed
- and issues the following fault report in the parameter
value (PWE):
PWE low
(Hex)
Fault Report
0 The parameter number used does not exit
1 There is no write access to the defined parameter
2 Data value exceeds the parameter's limits
3 The sub index used does not exit
4 The parameter is not the array type
5 The data type does not match the defined
parameter
11 Data change in the defined parameter is not
possible in the frequency converter's present
mode. Certain parameters can only be changed
when the motor is turned off
82 There is no bus access to the defined parameter
83 Data change is not possible because factory set-
up is selected
Table 12.6 Parameter Value Fault Report
12.7.8
Parameter Number (PNU)
Bits no. 0-11 transfer parameter numbers. The function of
the relevant parameter is defined in the parameter
description in the Programming Guide.
12.7.9
Index (IND)
The index is used together with the parameter number to
read/write-access parameters with an index, e.g.
15-30 Alarm Log: Error Code. The index consists of 2 bytes,
a low byte and a high byte.
Only the low byte is used as an index.
12.7.10
Parameter Value (PWE)
The parameter value block consists of 2 words (4 bytes),
and the value depends on the defined command (AK). The
master prompts for a parameter value when the PWE block
contains no value. To change a parameter value (write),
write the new value in the PWE block and send from the
master to the follower.
When a follower responds to a parameter request (read
command), the present parameter value in the PWE block
is transferred and returned to the master. If a parameter
contains not a numerical value, but several data options,
e.g. 0-01 Language where [0] is English, and [4] is Danish,
select the data value by entering the value in the PWE
block. See Example - Selecting a data value. Serial
communication is only capable of reading parameters
containing data type 9 (text string).
RS-485 Installation and Set...
VLT
®
AutomationDrive FC 301/FC 302 Design Guide, 0.25-75 kW
180 MG33BF02 - Rev. 2013-12-20
1212
