Danfoss VLT AutomationDrive FC 301 Design Guide

6 Product Specifications
6.1 Electrical Data
6.1.1 Mains Supply 200-240 V
Type Designation PK25 PK37 PK55 PK75 P1K1 P1K5 P2K2 P3K0 P3K7
Typical Shaft Output [kW] 0.25 0.37 0.55 0,75 1.1 1.5 2.2 3.0 3.7
Enclosure IP20 (FC 301 only) A1 A1 A1 A1 A1 A1 - - -
Enclosure IP20/IP21 A2 A2 A2 A2 A2 A2 A2 A3 A3
Enclosure IP55, IP66 A4/A5 A4/A5 A4/A5 A4/A5 A4/A5 A4/A5 A4/A5 A5 A5
Output current
Continuous (200-240 V) [A] 1.8 2.4 3.5 4.6 6.6 7.5 10.6 12.5 16.7
Intermittent (200-240 V) [A] 2.9 3.8 5.6 7.4 10.6 12.0 17.0 20.0 26.7
Continuous kVA (208 V) [kVA] 0.65 0.86 1.26 1.66 2.38 2.70 3.82 4.50 6.00
Max. input current
Continuous (200-240 V) [A] 1.6 2.2 3.2 4.1 5.9 6.8 9.5 11.3 15.0
Intermittent (200-240 V) [A] 2.6 3.5 5.1 6.6 9.4 10.9 15.2 18.1 24.0
Additional Specifications
Max. cable cross section
4)
for mains, motor,
brake and load sharing [mm
2
] ([AWG])
4,4,4 (12,12,12)
(min. 0.2 (24))
Max. cable cross section
4)
for disconnect
[mm
2
] ([AWG])
6,4,4 (10,12,12)
Estimated power loss at rated max. load [W]
3)
21 29 42 54 63 82 116 155 185
Efficiency
2)
0.94 0.94 0.95 0.95 0.96 0.96 0.96 0.96 0.96
Table 6.1 Mains Supply 200-240 V, PK25-P3K7
