Danfoss VLT AutomationDrive FC 301 Design Guide

Type Designation P5K5 P7K5 P11K
High/Normal Overload
1)
HO NO HO NO HO NO
Typical Shaft Output [kW] 5.5 7.5 7.5 11 11 15
Enclosure IP20 B3 B3 B4
Enclosure IP21, IP55, IP66 B1 B1 B2
Output current
Continuous (200-240 V) [A] 24.2 30.8 30.8 46.2 46.2 59.4
Intermittent (60 s overload) (200-240 V) [A] 38.7 33.9 49.3 50.8 73.9 65.3
Continuous kVA (208 V) [kVA] 8.7 11.1 11.1 16.6 16.6 21.4
Max. input current
Continuous (200-240 V) [A] 22.0 28.0 28.0 42.0 42.0 54.0
Intermittent (60 s overload) (200-240 V) [A] 35.2 30.8 44.8 46.2 67.2 59.4
Additional Specifications
IP20 max. cable cross-section
4)
for mains, brake, motor and load
sharing [mm
2
] ([AWG])
10,10,- (8,8,-) 10,10,- (8,8,-) 35,-,- (2,-,-)
IP21 max. cable cross-section
4)
for mains, brake and load sharing
[mm
2
] ([AWG])
16,10,16 (6,8,6) 16,10,16 (6,8,6) 35,-,- (2,-,-)
IP21 max. cable cross-section
4)
for motor [mm
2
] ([AWG])
10,10,- (8,8,-) 10,10,- (8,8,-) 35,25,25 (2,4,4)
Max. cable cross-section
4)
for Disconnect [mm
2
] ([AWG])
16,10,10 (6,8,8)
Estimated power loss at rated max. load [W]
3)
239 310 371 514 463 602
Efficiency
2)
0.96 0.96 0.96
Table 6.2 Mains Supply 200-240 V, P5K5-P11K
Type Designation P15K P18K P22K P30K P37K
High/Normal Overload
1)
HO NO HO NO HO NO HO NO HO NO
Typical Shaft Output [kW] 15 18.5 18.5 22 22 30 30 37 37 45
Enclosure IP20 B4 C3 C3 C4 C4
Enclosure IP21, IP55, IP66 C1 C1 C1 C2 C2
Output current
Continuous (200-240 V) [A] 59.4 74.8 74.8 88.0 88.0 115 115 143 143 170
Intermittent (60 s overload) (200-240 V) [A] 89.1 82.3 112 96.8 132 127 173 157 215 187
Continuous kVA (208 V [kVA] 21.4 26.9 26.9 31.7 31.7 41.4 41.4 51.5 51.5 61.2
Max. input current
Continuous (200-240 V) [A] 54.0 68.0 68.0 80.0 80.0 104 104 130 130 154
Intermittent (60 s overload) (200-240 V) [A] 81.0 74.8 102 88.0 120 114 156 143 195 169
Additional Specifications
IP20 max. cable cross-section for mains, brake,
motor and load sharing [mm
2
] ([AWG])
35 (2) 50 (1) 50 (1) 150 (300MCM) 150 (300MCM)
IP21, IP55, IP66 max. cable cross-section for
mains and motor [mm
2
] ([AWG])
50 (1) 50 (1) 50 (1) 150 (300MCM) 150 (300MCM)
IP21, IP55, IP66 max. cable cross-section for
brake and load sharing [mm
2
] ([AWG])
50 (1) 50 (1) 50 (1) 95 (3/0) 95 (3/0)
Max. cable cross-section
4)
for Disconnect [mm
2
]
([AWG])
50, 35, 35 (1, 2, 2)
95, 70, 70
(3/0, 2/0, 2/0)
185, 150, 120
(350MCM,
300MCM, 4/0)
Estimated power loss at rated max. load [W]
3)
624 737 740 845 874 1140 1143 1353 1400 1636
Efficiency
2)
0.96 0.97 0.97 0.97 0.97
Table 6.3 Mains Supply 200-240 V, P15K-P37K
Product Specifications
VLT
®
AutomationDrive FC 301/FC 302 Design Guide, 0.25-75 kW
MG33BF02 - Rev. 2013-12-20 59
6 6
