Danfoss VLT AutomationDrive FC 301 Design Guide

6.1.2 Mains Supply 380-500 V
Type Designation PK37 PK55 PK75 P1K1 P1K5 P2K2 P3K0 P4K0 P5K5 P7K5
Typical Shaft Output [kW] 0.37 0.55 0,75 1.1 1.5 2.2 3.0 4.0 5.5 7.5
Enclosure IP20 (FC 301 only) A1 A1 A1 A1 A1 - - - - -
Enclosure IP20/IP21 A2 A2 A2 A2 A2 A2 A2 A2 A3 A3
Enclosure IP55, IP66 A4/A5 A4/A5 A4/A5 A4/A5 A4/A5 A4/A5 A4/A5 A4/A5 A5 A5
Output current High overload 160% for 1 min
Shaft output [kW] 0.37 0.55 0.75 1.1 1.5 2.2 3 4 5.5 7.5
Continuous (380-440 V) [A] 1.3 1.8 2.4 3.0 4.1 5.6 7.2 10 13 16
Intermittent (380-440 V) [A] 2.1 2.9 3.8 4.8 6.6 9.0 11.5 16 20.8 25.6
Continuous (441-500 V) [A] 1.2 1.6 2.1 2.7 3.4 4.8 6.3 8.2 11 14.5
Intermittent (441-500 V) [A] 1.9 2.6 3.4 4.3 5.4 7.7 10.1 13.1 17.6 23.2
Continuous kVA (400 V) [kVA] 0.9 1.3 1.7 2.1 2.8 3.9 5.0 6.9 9.0 11
Continuous kVA (460 V) [kVA] 0.9 1.3 1.7 2.4 2.7 3.8 5.0 6.5 8.8 11.6
Max. input current
Continuous (380-440 V) [A] 1.2 1.6 2.2 2.7 3.7 5.0 6.5 9.0 11.7 14.4
Intermittent (380-440 V) [A] 1.9 2.6 3.5 4.3 5.9 8.0 10.4 14.4 18.7 23
Continuous (441-500 V) [A] 1.0 1.4 1.9 2.7 3.1 4.3 5.7 7.4 9.9 13
Intermittent (441-500 V) [A] 1.6 2.2 3.0 4.3 5.0 6.9 9.1 11.8 15.8 20.8
Additional Specifications
IP20, IP21 max. cable cross-section
4)
for mains,
motor, brake and load sharing [mm
2
] ([AWG])
4,4,4 (12,12,12)
(min. 0.2(24))
IP55, IP66 max. cable cross-section
4)
for mains,
motor, brake and load sharing [mm
2
] ([AWG])
4,4,4 (12,12,12)
Max. cable cross-section
4)
for disconnect
[mm
2
] ([AWG])
6,4,4 (10,12,12)
Estimated power loss at rated max. load [W]
3)
35 42 46 58 62 88 116 124 187 255
Efficiency
2)
0.93 0.95 0.96 0.96 0.97 0.97 0.97 0.97 0.97 0.97
Table 6.4 Mains Supply 380-500 V (FC 302), 380-480 V (FC 301), PK37-P7K5
Product Specifications
VLT
®
AutomationDrive FC 301/FC 302 Design Guide, 0.25-75 kW
60 MG33BF02 - Rev. 2013-12-20
