7.2.6 Other Flat Pack Brake Resistors
FC 301
P
m
R
min
R
br, nom
Flat pack IP65 for horizontal conveyors
R
rec
per item
Duty cycle Ordering no.
T2 [kW]
[Ω] [Ω] [Ω//W]
[%] 175Uxxxx
PK25 0.25 368 416 430/100 40 1002
PK37 0.37 248 281 330/100 or 310/200 27 or 55 1003 or 0984
PK55 0.55 166 189 220/100 or 210/200 20 or 37 1004 or 0987
PK75 0.75 121 138 150/100 or 150/200 14 or 27 1005 or 0989
P1K1 1.1 81.0 92 100/100 or 100/200 10 or 19 1006 or 0991
P1K5 1.5 58.5 66.5 72/200 14 0992
P2K2 2.2 40.2 44.6 50/200 10 0993
P3K0 3 29.1 32.3 35/200 or 72/200 7 14 0994 or 2 x 0992
P3K7 3.7 22.5 25.9 60/200 11 2 x 0996
Table 7.17 Other Flat Packs for Frequency Converters with Mains Supply
FC 301 Mains: 200-240 V (T2)
FC 302
P
m
R
min
R
br. nom
Flat pack IP65 for horizontal conveyors
R
rec
per item
Duty cycle Ordering no.
T2 [kW]
[Ω] [Ω] [Ω/W]
[%] 175Uxxxx
PK25 0.25 380 475 430/100 40 1002
PK37 0.37 275 321 330/100 or 310/200 27 or 55 1003 or 0984
PK55 0.55 188 216 220/100 or 210/200 20 or 37 1004 or 0987
PK75 0.75 130 158 150/100 or 150/200 14 or 27 1005 or 0989
P1K1 1.1 81.0 105.1 100/100 or 100/200 10 or 19 1006 or 0991
P1K5 1.5 58.5 76.0 72/200 14 0992
P2K2 2.2 45.0 51.0 50/200 10 0993
P3K0 3 31.5 37.0 35/200 or 72/200 7 or 14 0994 or 2 x 0992
P3K7 3.7 22.5 29.7 60/200 11 2 x 0996
Table 7.18 Other Flat Packs for Frequency Converters with Mains Supply
FC 302 Mains: 200-240 V (T2)
FC 301
P
m
R
min
R
br. nom
Flat pack IP65 for horizontal conveyors
R
rec
per item Duty cycle Ordering no.
T4 [kW]
[Ω] [Ω] [Ω/W]
[%] 175Uxxxx
PK37 0.37 620 1121 830/100 30 1000
PK55 0.55 620 750 830/100 20 1000
PK75 0.75 485 548 620/100 or 620/200 14 or 27 1001 or 0982
P1K1 1.1 329 365 430/100 or 430/200 10 or 20 1002 or 0983
P1K5 1.5 240.0 263.0 310/200 14 0984
P2K2 2.2 161.0 176.5 210/200 10 0987
P3K0 3 117.0 127.9 150/200 or 300/200 7 or 14 0989 or 2 x 0985
P4K0 4 87 95 240/200 10 2 x 0986
P5K5 5.5 63 68 160/200 8 2 x 0988
P7K5 7.5 45 50 130/200 6 2 x 0990
P11K 11 34.9 38.0 80/240 5 2 x 0090
P15K 15 25.3 27.7 72/240 4 2 x 0091
Table 7.19 Other Flat Packs for Frequency Converters with Mains Supply
FC 301 Mains: 380-480 V (T4)
How to Order
VLT
®
AutomationDrive FC 301/FC 302 Design Guide, 0.25-75 kW
MG33BF02 - Rev. 2013-12-20 99
7 7
