Danfoss VLT AutomationDrive FC 301 Design Guide

1-00 Configuration
Mode
[1] Speed closed loop
1-01 Motor Control
Principle
[3] Flux with feedback
1-10 Motor
Construction
[1] PM, non salient SPM
1-24 Motor Current Nameplate
1-25 Motor Nominal
Speed
Nameplate
1-26 Motor Cont. Rated
Torque
Nameplate
AMA is not possible on PM motors
1-30 Stator Resistance
(Rs)
Motor data sheet
30-80 d-axis Inductance
(Ld)
Motor data sheet (mH)
1-39 Motor Poles Motor data sheet
1-40 Back EMF at 1000
RPM
Motor data sheet
1-41 Motor Angle Offset Motor data sheet (Usually zero)
17-50 Poles Resolver data sheet
17-51 Input Voltage Resolver data sheet
17-52 Input Frequency Resolver data sheet
17-53 Transformation
Ratio
Resolver data sheet
17-59 Resolver Interface [1] Enabled
Table 11.3 Parameters to Adjust
11.2.4
VLT
®
Relay Card MCB 105
The Relay Option MCB 105 includes 3 pieces of SPDT contacts and must be fitted into option slot B.
Electrical Data
Max terminal load (AC-1)
1)
(Resistive load) 240 V AC 2 A
Max terminal load (AC-15 )
1)
(Inductive load @ cosφ 0.4) 240 V AC 0.2 A
Max terminal load (DC-1)
1)
(Resistive load) 24 V DC 1 A
Max terminal load (DC-13)
1)
(Inductive load) 24 V DC 0.1 A
Min terminal load (DC) 5 V 10 mA
Max switching rate at rated load/min load 6 min
-1
/20 s
-1
1) IEC 947 part 4 and 5
When the relay option kit is ordered separately the kit
includes
•
Relay Module MCB 105
•
Enlarged LCP fixture and enlarged terminal cover
•
Label for covering access to switches S201, S202
and S801
•
Cable strips for fastening cables to relay module
Options and Accessories
VLT
®
AutomationDrive FC 301/FC 302 Design Guide, 0.25-75 kW
MG33BF02 - Rev. 2013-12-20 157
11 11
