Danfoss VLT AutomationDrive FC 301 Design Guide

Description Pos Possible choices
Software
release
24-
27
SXXX: Latest release - standard software
Software
language
28 X: Not used
1): FC 301/enclosure type A1 only
2) US Market only
3): A and B3 frames have load-sharing built-in by default
Table 7.1 Ordering Type Code Enclosure types A, B
and C
Description Pos Possible choices
A options 29-
30
AX: No A option
A0: MCA 101 Profibus DP V1 (standard)
A4: MCA 104 DeviceNet (standard)
A6: MCA 105 CANOpen (standard)
AN: MCA 121 Ethernet IP
AL: MCA 120 ProfiNet
AQ: MCA 122 Modbus TCP
AT: MCA 113 Profibus converter VLT
3000
AU: MCA 114 Profibus Converter VLT
5000
AY: MCA 123 Powerlink
A8: MCA 124 EtherCAT
B options 31-
32
BX: No option
BK: MCB 101 General purpose I/O
option
BR: MCB 102 Encoder option
BU: MCB 103 Resolver option
BP: MCB 105 Relay option
BZ: MCB 108 Safety PLC Interface
B2: MCB 112 PTC Thermistor Card
B4: MCB 114 VLT Sensor Input
B6: MCB 150 Safe Option TTL
B7: MCB 151 Safe Option HTL
C0 options 33-
34
CX: No option
C4: MCO 305, Programmable Motion
Controller
C1 options 35 X: No option
R: MCB 113 Ext. Relay Card
Z: MCA 140 Modbus RTU OEM option
C option
software/E1
options
36-
37
XX: Standard controller
10: MCO 350 Synchronizing control
11: MCO 351 Positioning control
D options 38-
39
DX: No option
D0: MCB 107 Ext. 24 V DC back-up
Table 7.2 Ordering Type Code, Options
NOTICE
For power sizes over 75 kW, see the VLT
®
AutomationDrive FC 300 90-1400 kW Design Guide.
How to Order
VLT
®
AutomationDrive FC 301/FC 302 Design Guide, 0.25-75 kW
MG33BF02 - Rev. 2013-12-20 83
7 7
