Danfoss VLT AutomationDrive FC 301 Design Guide

FC 301 Vertical braking 40% duty cycle
Frequency converter data
Brake resistor data Installation
R
rec
[Ω]
P
br.cont.
[kW]
Danfoss part number
Cable
cross
section
[mm
2
]
Thermo
relay
[A]
Mains
type
P
m
[kW]
R
min
[Ω]
R
br.nom
[Ω]
Wire IP54
Screw
terminal
IP21
Screw
terminal
IP65
Bolt
connection
IP20
T4 0.37 1000 1121.4 1200 0.200 175u3101 - - - 1.5 0.4
T4 0.55 620 749.8 850 0.200 175u3308 - - - 1.5 0.5
T4 0.75 485 547.6 630 0.300 175u3309 - - - 1.5 0.7
T4 1.1 329 365.3 410 0.450 175u3310 175u3416 175u3415 - 1.5 1
T4 1.5 240 263.0 270 0.570 175u3311 175u3418 175u3417 - 1.5 1.4
T4 2.2 161 176.5 200 0.960 175u3312 175u3420 175u3419 - 1.5 2.1
T4 3 117 127.9 145 1.130 175u3313 175u3422 175u3421 - 1.5 2.7
T4 4 86.9 94.6 110 1.700 175u3314 175u3424 175u3423 - 1.5 3.7
T4 5.5 62.5 68.2 80 2.200 175u3315 175u3138 175u3139 - 1.5 5
T4 7.5 45.3 49.6 56 3.200 175u3316 175u3428 175u3427 - 1.5 7.1
T4 11 34.9 38.0 38 5.000 - - - 175u3236 1.5 11.5
T4 15 25.3 27.7 28 6.000 - - - 175u3237 2.5 14.7
T4 18.5 20.3 22.3 22 8.000 - - - 175u3238 4 19
T4 22 16.9 18.7 19 10.000 - - - 175u3203 4 23
T4 30 13.2 14.5 14 14.000 - - - 175u3206 10 32
T4 37 10.6 11.7 12 17.000 - - - 175u3210 10 38
T4 45 8.7 9.6 9.5 21.000 - - - 175u3213 16 47
T4 55 6.6 7.8 7.0 26.000 - - - 175u3216 25 61
T4 75 4.2 5.7 5.5 36.000 - - - 175u3219 35 81
Table 7.9 T4, Vertical Braking 40% Duty Cycle
How to Order
VLT
®
AutomationDrive FC 301/FC 302 Design Guide, 0.25-75 kW
MG33BF02 - Rev. 2013-12-20 91
