Danfoss VLT AutomationDrive FC 301 Design Guide

FC 302 Vertical braking 40% duty cycle
Frequency converter data
Brake resistor data Installation
R
rec
[Ω]
P
br.cont.
[kW]
Danfoss part number
Cable
cross
section
[mm
2
]
Thermo
relay
[A]
Mains
type
P
m
[kW]
R
min
[Ω]
R
br.nom
[Ω]
Wire IP54
Screw
terminal
IP21
Screw
terminal
IP65
Bolt
connection
IP20
T5 0.37 1000 1389.2 1200 0.200 175u3101 - - - 1.5 0.4
T5 0.55 620 928.8 850 0.200 175u3308 - - - 1.5 0.5
T5 0.75 558 678.3 630 0.300 175u3309 - - - 1.5 0.7
T5 1.1 382 452.5 410 0.450 175u3310 175u3416 175u3415 - 1.5 1
T5 1.5 260 325.9 270 0.570 175u3311 175u3418 175u3417 - 1.5 1.4
T5 2.2 189 218.6 200 0.960 175u3312 175u3420 175u3419 - 1.5 2.1
T5 3 135 158.5 145 1.130 175u3313 175u3422 175u3421 - 1.5 2.7
T5 4 99.0 117.2 110 1.700 175u3314 175u3424 175u3423 - 1.5 3.7
T5 5.5 72.0 84.4 80 2.200 175u3315 175u3138 175u3139 - 1.5 5
T5 7.5 50.0 61.4 56 3.200 175u3316 175u3428 175u3427 - 1.5 7.1
T5 11 36.0 41.2 38 5.000 - - - 175u3236 1.5 11.5
T5 15 27.0 30.0 28 6.000 - - - 175u3237 2.5 14.7
T5 18.5 20.3 24.2 22 8.000 - - - 175u3238 4 19
T5 22 18.0 20.3 19 10.000 - - - 175u3203 4 23
T5 30 13.4 15.8 14 14.000 - - - 175u3206 10 32
T5 37 10.8 12.7 12 17.000 - - - 175u3210 10 38
T5 45 8.8 10.4 9.5 21.000 - - - 175u3213 16 47
T5 55 6.5 8.5 7.0 26.000 - - - 175u3216 25 61
T5 75 4.2 6.2 5.5 36.000 - - - 175u3219 35 81
Table 7.13 T5, Vertical Braking 40% Duty Cycle
How to Order
VLT
®
AutomationDrive FC 301/FC 302 Design Guide, 0.25-75 kW
MG33BF02 - Rev. 2013-12-20 95
7 7
