Danfoss vlt FC 102 Programming Guide

8-13 Congurable Status Word STW
This parameter enables conguration of bits 12–15 in the status
word.
Array [16]
Option: Function:
[71] Logic Rule 1 See parameter group 13-4* Logic
Rules. If logic rule 1 is evaluated as
true, the output goes high.
Otherwise, it is low.
[72] Logic Rule 2 See parameter group 13-4* Logic
Rules. If logic rule 2 is evaluated as
true, the output goes high.
Otherwise, it is low.
[73] Logic Rule 3 See parameter group 13-4* Logic
Rules. If logic rule 3 is evaluated as
true, the output goes high.
Otherwise, it is low.
[74] Logic Rule 4 See parameter group 13-4* Logic
Rules. If logic rule 4 is evaluated as
true, the output goes high.
Otherwise, it is low.
[75] Logic Rule 5 See parameter group 13-4* Logic
Rules. If logic rule 5 is evaluated as
true, the output goes high.
Otherwise, it is low.
[80] SL digital out
A
See parameter 13-52 SL Controller
Action. The output goes high
whenever the smart logic action
[38] Set digital out A high is
executed. The output goes low
whenever the smart logic action
[32] Set digital out A low is
executed.
[81] SL digital out
B
See parameter 13-52 SL Controller
Action. The output goes high
whenever the smart logic action
[39] Set digital out B high is
executed. The output goes low
whenever the smart logic action
[33] Set digital out B low is executed.
[82] SL digital out
C
See parameter 13-52 SL Controller
Action. The output goes high
whenever the smart logic action
[40] Set digital out C high is
executed. The output goes low
whenever the smart logic action
[34] Set digital out C low is
executed.
[83] SL digital out
D
See parameter 13-52 SL Controller
Action. The output goes high
whenever the smart logic action
[41] Set digital out D high is
executed. The output goes low
8-13 Congurable Status Word STW
This parameter enables conguration of bits 12–15 in the status
word.
Array [16]
Option: Function:
whenever the smart logic action
[35] Set digital out D low is
executed.
[84] SL digital out
E
See parameter 13-52 SL Controller
Action. The output goes high
whenever the smart logic action
[42] Set digital out E high is
executed. The output goes low
whenever the smart logic action
[36] Set digital out E low is executed.
[85] SL digital out
F
See parameter 13-52 SL Controller
Action. The output goes high
whenever the smart logic action
[43] Set digital out F high is
executed. The output goes low
whenever the smart logic action
[37] Set digital out F low is executed.
[86] ATEX ETR cur.
alarm
[87] ATEX ETR freq.
alarm
[88] ATEX ETR cur.
warning
[89] ATEX ETR freq.
warning
[181] Prev.
Maintenance
[190] No-Flow
[191] Dry Pump
[192] End Of Curve
[193] Sleep Mode
[194] Broken Belt
[196] Fire Mode
[197] Fire Mode was
Act.
[200] User Dened
Alerts
8-14 Congurable Control Word CTW
Option: Function:
[0] None
[1] * Prole default
[2] CTW Valid,
active low
[7] External
Interlock
[15] Relay 1
[16] Relay 2
[22] Digital Out 27
Parameter Descriptions Programming Guide
M0010001 Danfoss A/S © 10/2019 All rights reserved. 117
3 3

Danfoss vlt FC 102 Specifications

General

Category	DC Drives
Model	Danfoss VLT FC 102
Output voltage range	0 to rated motor voltage
Power range	0.37 kW to 200 kW
Communication interfaces	RS-485
Protection features	Overvoltage, undervoltage, overcurrent, short circuit, earth fault, overtemperature, motor thermal protection
Cooling method	Air-cooled
Enclosure rating	IP20, IP21, IP55 (depending on model)
Approvals	CE, UL, cUL
