Parameter 13-90 Alert Trigger = [37] Digital input
DI32.
•
Parameter 13-91 Alert Action = [5] Stop & warning.
•
Parameter 13-92 Alert Text = Valve 5 open.
13-90 Alert Trigger
Array [10]
Select the event that triggers the user-dened action and
message.
Option: Function:
[0] * False
[1] True
[18] Reversing
[22] Comparator 0
[23] Comparator 1
[24] Comparator 2
[25] Comparator 3
[26] Logic rule 0
[27] Logic rule 1
[28] Logic rule 2
[29] Logic rule 3
[30] SL Time-out 0
[31] SL Time-out 1
[32] SL Time-out 2
[33] Digital input
DI18
[34] Digital input
DI19
[35] Digital input
DI27
[36] Digital input
DI29
[37] Digital input
DI32
[38] Digital input
DI33
[50] Comparator 4
[51] Comparator 5
[60] Logic rule 4
[61] Logic rule 5
[70] SL Time-out 3
[71] SL Time-out 4
[72] SL Time-out 5
[73] SL Time-out 6
[74] SL Time-out 7
[90] ECB Drive
Mode
[91] ECB Bypass
Mode
[144] Pressure 1
Low
[145] Pressure 2
Low
[146] Pressure 3
Low
13-90 Alert Trigger
Array [10]
Select the event that triggers the user-dened action and
message.
Option: Function:
[147] Pressure 4
Low
[148] Pressure 1
High
[149] Pressure 2
High
[150] Pressure 3
High
[151] Pressure 4
High
13-91 Alert Action
Array [10]
Select the action that the frequency converter performs when
the event dened in parameter 13-90 Alert Trigger occurs.
Option: Function:
[0] * Info
[1] Warning
[2] Freeze output
[3] Freeze output
& warn
[4] Stop
[5] Stop &
warning
[6] Jogging
[7] Jogging &
warning
[8] Max speed
[9] Max speed &
warn
[10] Stop and trip
[11] Stop and trip
w manual
reset
[12] Trip
[13] Trip w manual
reset
[14] Trip Lock
13-92 Alert Text
Range: Function:
Size
related*
[0 - 20 ] Array [10]
Enter the text that the frequency
converter shows in the display
when the event dened in
parameter 13-90 Alert Trigger occurs.
Parameter Descriptions Programming Guide
M0010001 Danfoss A/S © 10/2019 All rights reserved. 145
