Danfoss vlt FC 102 Programming Guide

23-01 ON Action
Array [10]
Option: Function:
[16] Select preset
ref 6
[17] Select preset
ref 7
[18] Select ramp 1
[19] Select ramp 2
[22] Run
[23] Run reverse
[24] Stop
[26] DC Brake
[27] Coast
[32] Set digital out
A low
[33] Set digital out
B low
[34] Set digital out
C low
[35] Set digital out
D low
[36] Set digital out
E low
[37] Set digital out
F low
[38] Set digital out
A high
[39] Set digital out
B high
[40] Set digital out
C high
[41] Set digital out
D high
[42] Set digital out
E high
[43] Set digital out
F high
[60] Reset Counter
A
[61] Reset Counter
B
[62] Counter A (up)
[63] Counter A
(down)
[64] Counter B (up)
[65] Counter B
(down)
[80] Sleep Mode
[90] Set ECB
Bypass Mode
[91] Set ECB Drive
Mode
[100] Reset Alarms
23-02 OFF Time
Array [10]
Range: Function:
Size
related*
[ 0 - 0 ] Sets the OFF time for the timed
action.
NOTICE
The frequency converter has
no back-up of the clock
function. The set date/time is
reset to default (2000-01-01
00:00) after a power-down
unless a real-time clock
module with back-up is
installed. In
parameter 0-79 Clock Fault, it is
possible to program a warning
if the clock has not been set
properly, for example after a
power-down.
23-03 OFF Action
Array [10]
Option: Function:
Select the action during OFF time.
See parameter 13-52 SL Controller
Action for descriptions of the
options.
[1] * No action
[2] Select set-up 1
[3] Select set-up 2
[4] Select set-up 3
[5] Select set-up 4
[10] Select preset
ref 0
[11] Select preset
ref 1
[12] Select preset
ref 2
[13] Select preset
ref 3
[14] Select preset
ref 4
[15] Select preset
ref 5
[16] Select preset
ref 6
[17] Select preset
ref 7
[18] Select ramp 1
[19] Select ramp 2
[22] Run
[23] Run reverse
[24] Stop
Parameter Descriptions
VLT
®
HVAC Drive FC 102
214 Danfoss A/S © 10/2019 All rights reserved. M0010001
33
