Danfoss vlt FC 102 Programming Guide

23-03 OFF Action
Array [10]
Option: Function:
[26] DC Brake
[27] Coast
[32] Set digital out
A low
[33] Set digital out
B low
[34] Set digital out
C low
[35] Set digital out
D low
[36] Set digital out
E low
[37] Set digital out
F low
[38] Set digital out
A high
[39] Set digital out
B high
[40] Set digital out
C high
[41] Set digital out
D high
[42] Set digital out
E high
[43] Set digital out
F high
[60] Reset Counter
A
[61] Reset Counter
B
[62] Counter A (up)
[63] Counter A
(down)
[64] Counter B (up)
[65] Counter B
(down)
[80] Sleep Mode
[90] Set ECB
Bypass Mode
[91] Set ECB Drive
Mode
[100] Reset Alarms
23-04 Occurrence
Array [10]
Option: Function:
Select which days the timed action
applies to. Specify working/non-
working days in:
23-04 Occurrence
Array [10]
Option: Function:
•
Parameter 0-81 Working
Days.
•
Parameter 0-82 Additional
Working Days.
•
Parameter 0-83 Additional
Non-Working Days.
[0] * All days
[1] Working days
[2] Non-working
days
[3] Monday
[4] Tuesday
[5] Wednesday
[6] Thursday
[7] Friday
[8] Saturday
[9] Sunday
[10] Day 1 of
month
[11] Day 2 of
month
[12] Day 3 of
month
[13] Day 4 of
month
[14] Day 5 of
month
[15] Day 6 of
month
[16] Day 7 of
month
[17] Day 8 of
month
[18] Day 9 of
month
[19] Day 10 of
month
[20] Day 11 of
month
[21] Day 12 of
month
[22] Day 13 of
month
[23] Day 14 of
month
[24] Day 15 of
month
[25] Day 16 of
month
[26] Day 17 of
month
Parameter Descriptions Programming Guide
M0010001 Danfoss A/S © 10/2019 All rights reserved. 215
3 3
