Danfoss vlt FC 102 Programming Guide

0-10 Active Set-up
Option: Function:
not changeable during operation
have dierent values.
Parameters which are not
changeable during operation are
marked FALSE in
chapter 5 Parameter Lists.
[0] Factory setup Cannot be changed. It contains the
Danfoss data set and can be used
as a data source when returning
the other set-ups to a known state.
[1] * Set-up 1 [1] Set-up 1 to [4] Set-up 4 are the 4
parameter set-ups within which all
parameters can be programmed.
[2] Set-up 2
[3] Set-up 3
[4] Set-up 4
[9] Multi Set-up Is used for remote set-up selections
using digital inputs and the serial
communication port. This set-up
uses the settings from
parameter 0-12 This Set-up Linked to.
0-11 Programming Set-up
Option: Function:
Select the setup to be edited (that
is programmed) during operation;
either the active setup or 1 of the
inactive setups. The setup number
being edited is shown in the LCP in
brackets.
[0] Factory setup Cannot be edited, but it is useful as
a data source to return the other
set-ups to a known state.
[1] Set-up 1 [1] Set-up 1 to [4] Set-up 4 can be
edited freely during operation,
independently of the active set-up.
[2] Set-up 2
[3] Set-up 3
[4] Set-up 4
[9] * Active Set-up The setup in which the frequency
converter is operating, can be
edited during operation. Editing
parameters in the selected setup
would normally be done from the
LCP, but it is also possible from any
of the serial communication ports.
0-12 This Set-up Linked to
Option: Function:
Use this parameter only if a change
of set-ups is required while the
0-12 This Set-up Linked to
Option: Function:
motor is running. This parameter
ensures that parameters which are
not changeable during operation
have the same setting in all
relevant set-ups.
To enable conict-free changes
from 1 set-up to another while the
frequency converter is running, link
set-ups containing parameters
which are not changeable during
operation. The link ensures synchro-
nizing of the not changeable during
operation parameter values when
moving from 1 set-up to another
during operation. Parameters
marked with FALSE in the
parameter lists (in
chapter 5 Parameter Lists) cannot be
changed while the frequency
converter is running.
The parameter 0-12 This Set-up
Linked to feature is used when [9]
Multi set-up in parameter 0-10 Active
Set-up is selected. Use [9] Multi set-
up to move from 1 set-up to
another during operation while the
motor is running.
For example:
Use [9] Multi set-up to shift from
set-up 1 to set-up 2 while the
motor is running. Program
parameters in set-up 1 rst, then
ensure that set-up 1 and set-up 2
are synchronized (or linked).
Synchronization can be performed
in 2 ways:
•
Change the edit set-up to
[2] Set-up 2 in
parameter 0-11 Programmi
ng Set-up and set
parameter 0-12 This Set-up
Linked to to [1] Set-up 1.
This starts the linking
(synchronizing) process.
130BP075.10
0-12 This Set-up Linked to
0 RPM
0.00A 1(1)
Set-up Handling 0-1*
[1]
Setup 1
Illustration 3.1 Set-up Handling
Parameter Descriptions Programming Guide
M0010001 Danfoss A/S © 10/2019 All rights reserved. 29
3 3
