Danfoss vlt FC 102 Operating Guide

Power [kW (hp)]
Bussmann Type
RK1
Bussmann
Type J
Bussmann
Type T
Bussmann
Type CC
Bussmann
Type CC
Bussmann
Type CC
55 (75)
KTS-R-150
JKS-150
JJS-150
–
–
–
75 (100)
KTS-R-200
JKS-200
JJS-200
–
–
–
90 (125)
KTS-R-250
JKS-250
JJS-250
–
–
–
Table 65: Recommended Maximum Fuse, 380–480 V, Enclosure Sizes A, B, and C
Power [kW
(hp)]
SIBA Type RK1
Littelfuse
Type RK1
Ferraz
Shawmut
Type CC
Ferraz Shaw-
mut Type RK1
Bussmann
JFHR2
Ferraz
Shawmut
J
Ferraz
Shawmut
JFHR2
(1)
Littelfuse
JFHR2
1.1 (1.5)
5017906-006
KLS-R-6
ATM-R-6
A6K-6-R
FWH-6
HSJ-6
–
–
1.5–2.2
(2.0–3.0)
5017906-010
KLS-R-10
ATM-R-10
A6K-10-R
FWH-10
HSJ-10
–
–
3.0 (4.0)
5017906-016
KLS-R-15
ATM-R-15
A6K-15-R
FWH-15
HSJ-15
–
–
4.0 (5.0)
5017906-020
KLS-R-20
ATM-R-20
A6K-20-R
FWH-20
HSJ-20
–
–
5.5 (7.5)
5017906-025
KLS-R-25
ATM-R-25
A6K-25-R
FWH-25
HSJ-25
–
–
7.5 (10)
5012406-032
KLS-R-30
ATM-R-30
A6K-30-R
FWH-30
HSJ-30
–
–
11–15 (15–
20)
5014006-040
KLS-R-40
–
A6K-40-R
FWH-40
HSJ-40
–
–
18.5 (25)
5014006-050
KLS-R-50
–
A6K-50-R
FWH-50
HSJ-50
–
–
22 (30)
5014006-063
KLS-R-60
–
A6K-60-R
FWH-60
HSJ-60
–
–
30 (40)
2028220-100
KLS-R-80
–
A6K-80-R
FWH-80
HSJ-80
–
–
37 (50)
2028220-125
KLS-R-100
–
A6K-100-R
FWH-100
HSJ-100
–
–
45 (60)
2028220-125
KLS-R-125
–
A6K-125-R
FWH-125
HSJ-125
–
–
55 (75)
2028220-160
KLS-R-150
–
A6K-150-R
FWH-150
HSJ-150
–
–
75 (100)
2028220-200
KLS-R-200
–
A6K-200-R
FWH-200
HSJ-200
A50-P-225
L50-
S-225
90 (125)
2028220-250
KLS-R-250
–
A6K-250-R
FWH-250
HSJ-250
A50-P-250
L50-
S-250
1
Ferraz Shawmut A50QS fuses may substitute for A50P fuses.
Table 66: Recommended Maximum Fuse, 525–600 V, Enclosure Sizes A, B, and C
Power
[kW
(hp)
Buss-
mann
Type
RK1
Buss-
mann
Type J
Buss-
mann
Type T
Buss-
mann
Type
CC
Buss-
mann
Type
CC
Buss-
mann
Type
CC
SIBA Type
RK1
Littel-
fuse
Type
RK1
Ferraz
Shawmut
Type RK1
Ferraz
Shaw-
mut J
1.1 (1.5)
KTS-R-5
JKS-5
JJS-6
FNQ-
R-5
KTK-R-5
LP-
CC-5
5017906-005
KLS-
R-005
A6K-5-R
HSJ-6
1.5–2.2
(2.0–
3.0)
KTS-
R-10
JKS-10
JJS-10
FNQ-
R-10
KTK-
R-10
LP-
CC-10
5017906-010
KLS-
R-010
A6K-10-R
HSJ-10
