Danfoss VLT Micro Drive FC 51 Design Guide

5.4.1 Ordering Numbers
200-240 V 380-480 V
Power [kW] Current [l-nom.] 1 ph. 3 ph. Current [l-nom.] 3 ph.
0.18 1.2 132F 0001
0.25 1.5 132F 0008
0.37 2.2 132F 0002 132F 0009 1.2 132F 0017
0.75 4.2 132F 0003 132F0010 2.2 132F 0018
1.5 6.8 132F 0005 132F0012 3.7 132F 0020
2.2 9.6 132F 0007 132F0014 5.3 132F 0022
3.0 7.2 132F 0024
3.7 15.2 132F 0016
4.0
Micro drives from 1.5 kW and up have built in brake chopper
9.0 132F 0026
5.5 12.0 132F 0028
7.5 15.5 132F 0030
11.0 23.0 132F 0058
15.0 31.0 132F 0059
18.5 37.0 132F 0060
22.0 43.0 132F 0061
Table 5.3
5.5.1 Options for VLT Micro Drive
Ordering No Description
132B0100 VLT Control Panel LCP 11 w/o potentiometer
132B0101 VLT Control Panel LCP 12 w/o potentiometer
132B0102 Remote Mounting Kit for LCP incl. 3 m cable IP55 with LCP 11, IP21 with LCP 12
132B0103 Nema Type 1 kit for M1 frame
132B0104 Type 1 kit for M2 frame
132B0105 Type 1 kit for M3 frame
132B0106 De-coupling plate kit for M1 and M2 frames
132B0107 De-coupling plate kit for M3 frame
132B0108 IP21 for M1 frame
132B0109 IP21 for M2 frame
132B0110 IP21 for M3 frame
132B0111 DIN rail mounting kit for M1 and M2 frame
132B0120 Type 1 kit for M4 frame
132B0121 Type 1 kit for M5 frame
132B0122 De-coupling plate kit for M4 and M5 frames
130B2522 Line Filter MCC 107 for 132F0001
130B2522 Line Filter MCC 107 for 132F0002
130B2533 Line Filter MCC 107 for 132F0003
130B2525 Line Filter MCC 107 for 132F0005
130B2530 Line Filter MCC 107 for 132F0007
130B2523 Line Filter MCC 107 for 132F0008
130B2523 Line Filter MCC 107 for 132F0009
130B2523 Line Filter MCC 107 for 132F0010
130B2526 Line Filter MCC 107 for 132F0012
130B2531 Line Filter MCC 107 for 132F0014
130B2527 Line Filter MCC 107 for 132F0016
130B2523 Line Filter MCC 107 for 132F0017
130B2523 Line Filter MCC 107 for 132F0018
130B2524 Line Filter MCC 107 for 132F0020
How to Order
VLT
®
Micro Drive FC 51 Design Guide
MG02K202 - VLT
®
is a registered Danfoss trademark
45
5 5
Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com

Danfoss VLT Micro Drive FC 51 Specifications

General

Enclosure	IP20
Output Voltage	0-100% of supply voltage
Altitude	Up to 1000 m without derating
Power Range	0.18-22 kW
Control Method	V/f
Communication	Modbus RTU
Protection Features	Over-voltage, under-voltage, over-current, over-temperature
Ambient Temperature	-10°C to 50°C
Storage Temperature	-25°C to 65°C
Relative Humidity	5-95% (non-condensing)
Input Voltage	200-240 V, 380-480 V
Braking Function	Integrated braking chopper (optional)
