Danfoss VLT Micro Drive FC 51 Design Guide

4.1.4 IP21/TYPE 1 Enclosure Kit
Frame IP class Power [kW] Height [mm]
A
Width [mm]
B
Depth [mm]
C
Ordering no.
1x200-240 V 3x200-240 V 3x380-480 V
M1 IP21 0.18-0.75 0.25-0.75 0.37-0.75 219.3 73 155.9 132B0108
M2 IP21 1.5 1.25 1.5-2.2 245.6 78 175.4 132B0109
M3 IP21 2.2 2.2-3.7 3.0-7.5 297.5 95 201.4 132B0110
M4 IP21 - - 11-15 - - - -
M5 IP21 - - 18.5-22 - - - -
Table 4.2
4.1.5 Type 1 (NEMA)
Frame IP class Power [kW] Height [mm]
A
Width [mm]
B
Depth [mm]
C
Ordering no.
1x200-240 V 3x200-240 V 3x380-480 V
M1 IP20 0.18-0.75 0.25-0.75 0.37-0.75 194.3 70.0 155.9 132B0103
M2 IP20 1.5 1.25 1.5-2.2 220.6 75.0 175.4 132B0104
M3 IP20 2.2 2.2-3.7 3.0-7.5 282.5 90.0 201.3 132B0105
M4 IP20 - - 11-15 345.6 125.0 248.5 132B0120
M5 IP20 - - 18.5-22 385.5 165.0 248.2 132B0121
Table 4.3
4.1.6 De-Coupling
Frame IP class Power [kW] Height [mm]
A
Width [mm]
B
Depth [mm]
C
Ordering no.
1x200-240 V 3x200-240 V 3x380-480 V
M1 IP20 0.18-0.75 0.25-0.75 0.37-0.75 204.2 70.0 155.9 132B0106
M2 IP20 1.5 1.25 1.5-2.2 230.0 75.0 175.4 132B0106
M3 IP20 2.2 2.2-3.7 3.0-7.5 218.5 90.0 201.3 132B0107
M4 IP20 - - 11-15 347.5 125.0 248.5 132B0122
M5 IP20 - - 18.5-22 387.5 165.0 248.2 132B0122
Table 4.4
VLT
®
Micro Drive Selection VLT
®
Micro Drive FC 51 Design Guide
30 MG02K202 - VLT
®
is a registered Danfoss trademark
44
Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com

Danfoss VLT Micro Drive FC 51 Specifications

General

Enclosure	IP20
Output Voltage	0-100% of supply voltage
Altitude	Up to 1000 m without derating
Power Range	0.18-22 kW
Control Method	V/f
Communication	Modbus RTU
Protection Features	Over-voltage, under-voltage, over-current, over-temperature
Ambient Temperature	-10°C to 50°C
Storage Temperature	-25°C to 65°C
Relative Humidity	5-95% (non-condensing)
Input Voltage	200-240 V, 380-480 V
Braking Function	Integrated braking chopper (optional)
