Dascom 1330 - 2 Setting Up Printer; 2.1 Install Ribbon

Tally Dascom 1330
4
2 Setting Up Printer
2.1 Install Ribbon
Switch printer off during Ribbon installation.
1. Open the Front Flap as shown in below picture.
2. Raise the Head Gap Lever to the top most position, labeled “ ”.
3. Pull the Upper Friction Frame ① and then lock it ② in place to the side plates.
