DataCard CP80 Plus

CP80 and CP80 Plus Service Manual 6-5
Screw Torque Specifications
Screw Location Torque (in-lbs)
Pick motor 8±0.8
Transport motor 8±0.8
Cam motor 8±0.8
Ribbon take-up motor 8±0.8
680 coupler cable screws 0.9±0.1
Magnetic stripe encoder set screw 1.2±0.1
Magnetic stripe encoder mounting screws 0.9±0.1
Laminator transport motor 8±0.8
Heater lift motor 8±0.8
Swingarm cover screws (locking option) 12±1.2
Key lock barrel nut 16±1.6
Key lock cam nut 12±1.2
