CP80 and CP80 Plus Service Manual 4-33
Error
Code
Symptom Comments
OP-01663 The supply material is not
ready in the L2 laminator.
 ERR_OPT2_FOIL_INDEX
The foil index was not seen as expected. This can
also include not seeing a smart card cutout.
• Make sure the sensor is clean and functioning.
• Make sure the sensor is fully inserted in its mounting
slot.
OP-01664 The supply material is broken in
the L2 laminator.
 ERR_OPT2_FOIL_BREAK
Encoder transitions were not seen when expected.
• Inspect the supply cassette for damage to the
encoder wheel.
• Check the function of the encoder sensor.
OP-01665 Out of supply material for the
L2 laminator.
 ERR_OPT2_FOIL_OUT
• Make sure the RFID tag is not reused from another
spool.
• Inspect the supply cassette for damage to the
encoder wheel.
• Check the function of the encoder sensor.
• When less than 10% of the supply remains, a broken
ribbon will be reported as out of supply.
OP-01669 The L2 laminator is unable to
communicate with the printer.
 ERR_OPT2_COMM_ERROR
The serial communication between the printer and
laminator is not working. Inspect the serial interface
cable.
OP 01671 Supply material in the L2
laminator is low.
 ERR_OPT2_SUPPLY_LOW
Make sure the RFID tag is not reused from another
spool.
OP 01672 The printer cannot identify the
supply material in the L2
laminator.
 ERR_OPT2_SUPPLY_TYPE
• Replace the foil with a new spool. The RFID tag
may be defective.
• Inspect the RFID antenna and cable.
• Install a different roll of material.
OP 01674 A card is lost in the L2
laminator.
 ERR_OPT2_CARD_LOST
The card was not seen by the card exit sensor.
• Make sure the sensor is fully seated in the chassis.
• Replace the sensor.
