TF-168 sticker and wire no. table
STICKER EXPLAINATION WIRE NO.
HDUD Valves for dispense head up/down 001
GRAB Valve for Grab Hand 000
ANDP Valve for Anti-drip plate 002
XR X approach sensor XR
YR Y approach sensor YR
ZR Z approach sensor ZR
INSR Injector sensor I15
SSR1 In-feed Conveyor Controller 007
SSR2 Dispensing Conveyor Controller 008
SSR3 Out-feed Conveyor Controller 009
SUD Valves for Trays A up/down 004
INFD Valves for Loading cylinder 010; 011
OUFD Valves for Un-loading cylinder 012
AUCA Valves for Aux. dispense head calibration 003
AUMV Valves for Aux. disp head forward/backward 005; 006
AURF Valves for Aux. Refill
AIR INLET Air inlet
POWER INLET Left side of power entrance
AC220V 1PHASE Up side of power entrance
RS485 RS485 signal wire
DSPSU DC24V power supply
CPU0 First LA50B CPU
SERVO LA50B SERVO
DIO0 First LA50B DIO
DIO1 Second LA50B DIO
DIO2 Third LA50B DIO
XAMP First LA50B DIO
YAMP Second LA50B DIO
ZAMP Third LA50B DIO
DSRLY-1 A~D DS Relay
DSRLY-2 D DS Relay
FS1 AC220V Fuse
FS2 AC220V Fuse
FS3 DC24V Fuse
FS4 AC24V Fuse
FS5 DC24V Fuse
FS6 DC24V Fuse
R1 Main Power controller
NFB1 Main Power breaker
NFB2 PSU breaker
MC1 Main Power magnetic connector
