AutoLab TF Dispenser Technical Manual – Revision 5
AutoLab TF dispensers Technical Manual TFTMTF / Rev 5.0 / 24
th
May 2006 Page 87 of 150
TF-88/128/168 Air-tube label table
LABEL EXPLAINATION FUNCTION
01 Dispense head up/down valve In
02 Dispense head up/down valve Out
03 Grab hand valve In
04 Grab hand valve Out
05 Anti-drip valve In
06 Anti-drip valve Out
07 A Tray up/down valve In
08 A Tray up/down valve Out
09 In-let valve In
10 In-let valve Out
11 Out-let valve In
12 Out-let valve Out
13 Aux. calibration valve In
14 Aux. calibration valve Out
15 Aux. front/back valve In
16 Aux. front/back valve Out
82/122/162 Aux. 82/122/162 refill valve In
83/123/163 Aux. 83/123/163 refill valve In
84/124/164 Aux. 84/124/164 refill valve In
85/125/165 Aux. 85/125/165 refill valve In
86/126/166 Aux. 86/126/166 refill valve In
87/127/167 Aux. 87/127/167 refill valve In
88/128/168 Aux. 88/128/168 refill valve In
