Datakom D-100 MK2 User Manual

D-100 MK2 User Manual Firmware V-6.3
K96D01-EN - 10 -
Before installation:
 Read the user manual carefully, determine the correct connection diagram.
 Remove all connectors and mounting brackets from the unit, then pass the unit through the
mounting opening.
 Put mounting brackets and tighten. Do not tighten too much, this can brake the enclosure.
 Make electrical connections with plugs removed from sockets, then place plugs to their sockets.
 Be sure that adequate cooling is provided.
 Be sure that the temperature of the environment will not exceed the maximum operating
temperature in any case.
Below conditions may damage the device:
 Incorrect connections.
 Incorrect power supply voltage.
 Voltage at measuring terminals beyond specified range.
 Voltage applied to digital inputs over specified range.
 Current at measuring terminals beyond specified range.
 Overload or short circuit at relay outputs
 Connecting or removing data terminals when the unit is powered-up.
 High voltage applied to communication ports.
 Ground potential differences at non-isolated communication ports.
 Excessive vibration, direct installation on vibrating parts.
Below conditions may cause abnormal operation:
 Power supply voltage below minimum acceptable level.
 Power supply frequency out of specified limits
 Phase order of voltage inputs not correct.
 Current transformers not matching related phases.
 Current transformer polarity incorrect.
 Missing grounding.
Current Transformers must be used for current
measurement.
No direct connection allowed.
1. INSTALLATION INSTRUCTIONS

Datakom D-100 MK2 Specifications

General

Brand	Datakom
Model	D-100 MK2
Category	Controller
Language	English
