D-100 MK2 User Manual Firmware V-6.3
K96D01-EN - 22 -
The Charge terminal is both an input and output.
When the engine is ready to run, this terminal supplies the excitation current to the charge alternator.
The excitation circuit is equivalent to a 2W lamp.
The threshold voltages for warning and shutdown alarm are adjustable through program parameter.
Structure:
 battery voltage output through 100 ohm resistor
 voltage measurement input
Output current:
100mA @12VDC
200mA @24VDC
Voltage measurement
resolution:
0.1VDC
Voltage measurement
accuracy:
2% + 0.1V (0.9V @30VDC)
Charge Fail Warning
Threshold:
adjustable
Charge Fail Shutdown
Alarm Threshold:
adjustable
Open circuit voltage:
battery positive
Overvoltage protection:
> 500VDC continuous, with respect to battery negative
Reverse voltage
protection:
-30VDC with respect to battery negative
Structure:
Negative pulling protected semiconductor output. One terminal is
connected to battery negative.
Function
programmable function, selectable from list.
Max continuous current:
1.0 ADC
Max switching voltage:
33 VDC
Overvoltage protection:
40 VDC
Short circuit protection:
> 1.7 ADC
Reverse voltage
protection:
500 VDC
3.9. -
3.6. CHARGE INPUT TERMINAL
3.7. -
3.10. DIGITAL OUTPUTS
3.8. -
