Datakom D-100 MK2 User Manual

D-100 MK2 User Manual Firmware V-6.3
K96D01-EN - 42 -
Term
Function
Technical data
Description
13
DIGITAL INPUT 1
Digital Inputs,
0-30Vdc
The input has programmable function.
Factory set as LOW OIL PRESSURE
SWITCH.
14
DIGITAL INPUT 2
The input has programmable function.
Factory set as HIGH TEMP SWITCH.
15
DIGITAL INPUT 3
The input has programmable function.
Factory set as EMERGENCY STOP.
16
DIGITAL INPUT 4
The input has programmable function.
Factory set as LOW COOLANT LEVEL
SWITCH.
17
CANBUS-H
Digital communication
port
Connect the J1939 port of an electronic
engine to these terminals. The 120 ohm
terminating resistors are inside the unit.
Please do not connect external resistors.
Use a twisted cable pair or coaxial cable
for best results.
18
CANBUS-L
Term
Function
Technical data
Description
52
GEN-L1
Generator phase
inputs, 0-300V-AC
Connect the generator phases to these
inputs. The generator phase voltages
upper and lower limits are programmable.
54
GEN-L2
56
GEN-L3
58
GENERATOR NEUTRAL
Input, 0-300V-AC
Neutral terminal for the generator phases.
Term
Function
Technical data
Description
59
CURR_1+
Current transformer
inputs, 5A-AC
Connect the generator current transformer
terminals to these inputs.
Do not connect the same current
transformer to other instruments otherwise
a unit fault will occur.
Connect each terminal of the transformer
to the unit’s related terminal.
Do not use common terminals. Do not use
grounding.
Correct polarity of connection is vital.
The rating of the transformers should be
identical for each of the 3 phases.
The secondary winding rating shall be 5
Amperes. (ex: 200/5 Amps).
60
CURR_1-
61
CURR_2+
62
CURR_2-
63
CURR_3+
64
CURR_3-
Term
Function
Technical data
Description
65
MAINS NEUTRAL
Input, 0-300V-AC
Neutral terminal for the mains phases.
67
MAINS-L3
Mains phase inputs,
0-300V-AC
Connect the mains phases to these inputs.
The mains voltages upper and lower limits
are programmable.
69
MAINS-L2
71
MAINS-L1
