D-100 MK2 User Manual Firmware V-6.3
K96D01-EN - 74 -
Parameter Definition
Unit
Min
Max
Factor
y Set
Description
116-Excess power
Warning Limit
kW
0
50000
0
If the genset active power goes above
this limit then the controller will give an
Excess Power Warning.
117-Nominal RPM
rpm
0
50000
1500
The nominal value of engine rpm. Low-
high rpm limits are defined by reference
to this value.
118-Nominal RPM-2
rpm
0
50000
1800
When secondary frequency is selected,
this is the nominal value of engine rpm.
Low-high rpm limits are defined by
reference to this value.
119-Nominal RPM-3
rpm
0
50000
1800
When tertiary frequency is selected, this
is the nominal value of engine rpm. Low-
high rpm limits are defined by reference
to this value.
120-Low RPM Warning
Limit
%
R-100
R+100
R-10%
If the engine rpm goes under this limit
when feeding the load, this will generate a
GENSET LOW RPM warning.
121-Low RPM Shutdown
Limit
%
R-100
R+100
R-15%
If the engine rpm goes under this limit
when feeding the load, this will generate a
GENSET LOW RPM shutdown alarm
and the engine will stop.
122-High RPM Warning
Limit
%
R-100
R+100
R+10%
If the engine rpm goes over this limit
when feeding the load, this will generate a
GENSET HIGH RPM warning.
123-High RPM
Shutdown Limit
%
R-100
R+100
R+15%
If the engine rpm goes over this limit
when feeding the load, this will generate a
GENSET HIGH RPM shutdown alarm
and the engine will stop.
124-RPM Fail Timer
sec
0
10
3
If the engine rpm goes outside of the
limits during this timer, an engine speed
fault will occur.
125-Overspeed
Overshoot Limit
%
HRSL
-100
HRSL
+100
HRSL
+10%
If the engine rpm goes over the “High
RPM Shutdown Limit” by this quantity,
this will generate immediately a GENSET
HIGH RPM shutdown alarm and the
engine will stop.
126-Low Charge Voltage
Warning Limit
V-DC
0
40
6.0
If the charge alternator voltage goes
under this limit, a charge alternator
voltage warning will occur.
127-Low Charge Voltage
Shutdown Limit
V-DC
0
40
4.0
If the charge alternator voltage goes
under this limit, a charge alternator
voltage shutdown will occur and the
engine will stop.
128-Charge Voltage Fail
Timer
sec
0
120
1
If the charge alternator voltage goes
under limits during this timer, a charge
alternator voltage fault will occur.
129-Engine Heating
Temperature
°C
0
80
0
If it is requested that the engine runs
without load until reaching a certain
temperature, this parameter defines the
temperature.
130-Engine Start Delay
min
0
720
1
This is the time between the mains fails
and the fuel solenoid turns on before
starting the genset. It prevents
unwanted genset operation in battery
backed-up loads.
