Label ID

Product Reference Guide

105

GTIN5 G5 473500 $C 244300

GTIN8

G8 473800 $D 244400

I2OF5

i 690000 N 4E0000

IATA

IA 494100 & 260000

Industrial 2 of 5

W 570000 W 570000

Interleaved 2 of 5 CIP HR

e 650000 e 650000

ISBN

I 490000 @ 400000

ISBT128

f 660000 f 660000

ISSN

n 6E0000 n 6E0000

MSI

@ 400000 Z 5A0000

Plessey

a 610000 a 610000

S25

s 730000 P 500000

UPCA

A 410000 C 430000

UPCA P2

A 410000 F 460000

UPCA P5

A 410000 G 470000

UPCA P8

A 410000 Q 510000

UPCE

E 450000 D 440000

UPCE P2

E 450000 H 480000

UPCE P5

E 450000 I 490000

UPCE P8

E 450000 E 450000

Symbology

USA Label ID set EU Label ID set
