Table 17. Expansion card riser configuration 2
PCIe slots Width Length Height Processor 1 Processor 2 Processor 2 Processor 2
Riser 1A Riser 2C Riser 3D Riser 4A
Slot 6 SW HL LP - x16 - -
Slot 7 SW HL FH - - - x16
NOTE: The expansion-card slots are not hot-swappable.
The following table provides guidelines for installing expansion cards to ensure proper cooling and mechanical fit. The expansion
cards with the highest priority should be installed first using the slot priority indicated. All the other expansion cards should be
installed in the card priority and slot priority order.
Table 18. Configuration 1: Riser 1A + Riser 2C + Riser 3D + Riser 4B
Card type Slot priority Maximum number of cards
Mellanox (NIC: 100 Gb - Full Height)
CX6
2 1
Mellanox (NIC: 100 Gb - Full Height)
Q56
2 1
Intel (NIC: 25 Gb - Full Height) SFP 2 1
Broadcom (NIC: 25 Gb - Full Height)
57414
2 1
Mellanox (NIC - Full Height) HDRV 2 1
Mellanox (NIC: 100 Gb - Low Profile)
CX6
6 1
Mellanox (NIC: 100 Gb - Low Profile)
Q56
6 1
Intel (NIC: 25 Gb - Low Profile) SFP 6 1
Broadcom (NIC: 25 Gb - Low Profile)
57414
6 1
Mellanox (NIC - Low Profile) HDRV 6 1
Inventec (PERC: 4 GB - Full Height/Low
Profile) H745
7 1
Inventec (BOSS - Full Height) S1V5 8 1
Nvidia (GPU - 40 GB) A100 21~24 1
Nvidia (GPU - 80 GB) A100 21~24 1
Broadcom (OCP3: 25 Gb) Internal 1
Intel (OCP3: 1 Gb) Internal 1
Mellanox (OCP3: 25 Gb) Internal 1
Table 19. Configuration 2: Riser 1A + Riser 2C + Riser 3D + Riser 4A
Card type Slot priority Maximum number of cards
Mellanox (NIC: 100 Gb - Full Height)
CX6
2, 7 2
Mellanox (NIC: 100 Gb - Full Height)
Q56
2, 7 2
Intel (NIC: 25 Gb - Full Height) SFP 2, 7 2
74 Installing and removing system components
