Table 19. Configuration 2: Riser 1A + Riser 2C + Riser 3D + Riser 4A
Card type Slot priority Maximum number of cards
Broadcom (NIC: 25 Gb - Full Height)
57414
2, 7 2
Mellanox (NIC - Full Height) HDRV 2, 7 2
Mellanox (NIC: 100 Gb - Low Profile)
CX6
6 1
Mellanox (NIC: 100 Gb - Low Profile)
Q56
6 1
Intel (NIC: 25 Gb - Low Profile) SFP 6 1
Broadcom (NIC: 25 Gb - Low Profile)
57414
6 1
Mellanox (NIC - Low Profile) HDRV 6 1
Nvidia (GPU - 40 GB) A100 21~24 1
Nvidia (GPU - 80 GB) A100 21~24 1
Broadcom (OCP3: 25 Gb) Internal 1
Intel (OCP3: 1 Gb) Internal 1
Mellanox (OCP3: 25 Gb) Internal 1
Removing the expansion card risers
Prerequisites
1. Follow the safety guidelines listed in the Safety instructions on page 23.
2. Follow the procedure listed in the Before working inside your system on page 24.
3. Disconnect any cables that are connected to the expansion card or the risers.
Steps
1. For Riser 1, loosen the captive screws on the riser.
a. Press the blue release tab and holding the edges lift the expansion card riser from the riser connector on the system
board.
NOTE: The numbers on the image do not depict the exact steps. The numbers are for representation of sequence.
Installing and removing system components 75
