4 Install the Stand.
5 Follow the procedure in After working inside your computer.
Hard drive
Removing the hard drive assembly
1 Follow the procedure in Before working inside your computer.
2 Remove the following components:
a Stand
b Back cover
3 To remove the hard drive assembly:
a Press down the tab securing the hard drive assembly to the system board shield [1].
b Slide and lift the hard drive assembly from the slot on the display assembly base [2].
Removing and Installing components
25
