Dell OptiPlex 7460 - Installing the Power Supply Unit -PSU

Installing the power supply unit -PSU
1 To install the PSU:
a Align and slide the PSU, in to the slot on the display assembly base [1].
b Replace the single screw (M3x5) that secures the PSU to the chassis [2].
Removing and Installing components
57
