Dell OptiPlex 7460 - Installing the Input and Output Bracket

Installing the Input and Output bracket
1 Align the slots on the Input and Output bracket (I/O) bracket with the ports on the system board.
2 Replace the three screws (M3x5) that secure the I/O bracket to the display assembly base.
