2 Install the following components:
a I/O bracket
b Base cover
c System board shield
d Back cover
e Stand
3 Follow the procedure in After working inside your computer.
Power button board
Removing the power button board
1 Follow the procedure in Before working inside your computer.
2 Remove the following components:
a Stand
b Back cover
c System board shield
d Base cover
e I/O bracket
f Speakers
3 To remove the power button board:
a Open the latch, and disconnect the power button board cable from the system board [1].
b Peel o the power button board cable from the display assembly base [2].
c Remove the single screw (M3x5) that secures the power button board to the middle frame [3].
d Lift the power-button board, along with its cable, o the middle frame [4].
Removing and Installing components
73
