Installing the power supply unit -PSU fan
1 To install the PSU fan:
a Align and place the PSU fan on the chassis [1].
b Replace the two (M3x5) screws that secure the PSU fan to the display assembly base [2].
c Connect the PSU fan cable to the socket on the system board [3].
d Route the power supply cables to the retention clips on the PSU fan.
60
Removing and Installing components
