4 Install the following components:
a Base cover
b System board shield
c Back cover
d Stand
5 Follow the procedure in After working inside your computer.
System board
Removing the system board
1 Follow the procedure in Before working inside your computer.
2 Remove the following components:
a Stand
b Back cover
c System board shield
d Base cover
e I/O bracket.
f Memory
g System fan
h Heat sink
i Processor
j Intel Optane
k SSD
l Hard drive
Removing and Installing components
65
