m WLAN card
3 Disconnect the following cables from the system board:
• PSU fan cable [1]
• Power supply unit cable [2]
• Backlight cable [3]
• Camera cable [4]
•
SIO_signal,SIO power,INT_ speaker, and DMIC cables [1]
• Power button board cable [2]
• LVDS cable [3]
66
Removing and Installing components
