Dell OptiPlex 7460 - Installing the Intel Optane Card

Installing the Intel Optane card
1 Replace the thermal pad on the rectangular outline marked on the system board [1].
2 Insert the Intel Optane card into the card slot on the system board [2].
3 Replace the screw (M2) that secures the Intel Optane card to the system board [3].
32
Removing and Installing components
