Dell PowerConnect 3524P

314 Configuring Switch Information
• Status — Indicates if the port is currently monitored ( Active ) or not monitored ( Ready ).
•
Remove — Removes the port mirroring session. The possible field values are:
–
Checked — Removes the selected port mirroring sessions.
–
Unchecked — Maintains the port mirroring session.
Adding a Port Mirroring Session
1 Open the Port Mirroring page.
2 Click Add .
The
Add Source Port page opens.
Figure 7-28. Add Source Port
3 Define the Source Port and the Ty p e fields.
4 Click Apply Changes .
The new source port is defined, and the device is updated.
Deleting a Copied Port from a Port Mirroring Session
1 Open the Port Mirroring page.
2 In the Source Ports table, select the port’s Remove check box.
3 Click Apply Changes .
The selected port mirroring session is deleted, and the device is updated.
Configuring a Port Mirroring Session Using CLI Commands
The following table summarizes the equivalent CLI commands for configuring a Port Mirroring session
as displayed in the Port Mirroring page.
Table 7-15. Port Mirroring CLI Commands
CLI Command Description
port monitor src-interface [rx | tx] Starts a port monitoring session.
