354 Configuring Switch Information
VLAN Port Membership Table
The VLAN Port Membership Table contains a Port Table for assigning ports to VLANs. Ports are
assigned to a VLAN by toggling through the Port Control settings. Ports can have the following values:
The VLAN Port Membership Table displays the ports and the ports states, as well as LAGs.
Assigning Ports to a VLAN Group
1
Open the
VLAN Membership
page.
2
Click the
VLAN ID
or
VLAN Name
option button and select a VLAN from the drop-down menu.
3
Select a port in the
Port Membership Table
, and assign the port a value.
4
Click
Apply Changes
.
The port is assigned to the VLAN group, and the device is updated.
Deleting a VLAN
1
Open the
VLAN Membership
page.
2
Click the
VLAN ID
or
VLAN Name
option button and select a VLAN from the drop-down menu.
3
Select the
Remove VLAN
check box.
4
Click
Apply Changes
.
The selected VLAN is deleted, and the device is updated.
Table 7-25. VLAN Port Membership Table
Port Control Definition
T The interface is a member of a VLAN. All packets forwarded by the interface are tagged.
The packets contain VLAN information.
U The interface is a VLAN member. Packets forwarded by the interface are untagged.
F The interface is denied membership to a VLAN.
Blank The interface is not a VLAN member. Packets associated with the interface are not forwarded.
