Dell PowerConnect 5424 User Manual

106 Configuring System Information
New Log Server IP Address — Defines the IP address of the new Log Server.
3
Define the fields.
4 Click Apply Changes .
The server is defined and added to the
Available Servers list.
Displaying the Remote Log Servers Table:
1 Open the Remote Log Server Settings page.
2 Click Show All .
The
Remote Log Servers Table page opens:
Figure 6-21. Remote Log Servers Table
Removing a Log Server from the Log Server Table Page:
1 Open the Remote Log Server Settings page.
2 Click Show All .
The
Remote Log Servers Table page opens.
3 Select a Remote Log Servers Table entry.
4 Select the Remove check box to remove the server(s).
5 Click Apply Changes .
The
Remote Log Servers Table entry is removed, and the device is updated.
Working with Remote Server Logs Using the CLI Commands
The following table summarizes the equivalent CLI command for working with remote server logs.
Table 6-15. Remote Log Server CLI Commands
CLI Command Description
logging (ipv4-address|ipv6-addres |hostname) [port port]
[severity level] [facility facility] description text]
Logs messages to a remote server.
no logging Deletes a syslog server.
show logging Displays the state of logging and the syslog messages.

Dell PowerConnect 5424 Specifications

General

Ports	24 x 10/100/1000Base-T
Switching Capacity	48 Gbps
Forwarding Rate	35.7 Mpps
VLAN Support	Yes
Rack Mountable	Yes
Power Supply	Internal
MAC Address Table Size	8K entries
RAM	128 MB
Flash Memory	16 MB
Voltage Required	100-240V AC
Management	Web, CLI, SNMP
Operating Temperature	0°C to 45°C
Storage Temperature	-20°C to 70°C
Humidity	10% to 90% (non-condensing)
Standards Compliance	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Remote Management Protocol	SNMP, RMON, Telnet
Features	QoS, VLAN, Link Aggregation
